Bold new styling
From NZ $114,900
Comfort & Design
The new RX’s wheelbase is two inches longer than the previous model, resulting in greater legroom, and a larger luggage compartment.
Rear seats slide, recline and fold virtually flat in a 60/40 split, while storage compartments are conveniently spread throughout the RX.
Stylised tail lamps wrap around the RX’s deeply carved side panels, and light up in a glamorous display of illumination.
Lexus’s iconic L-shaped clearance lamps complement the LED headlights, so your vehicle is immediately recognisable as a Lexus.
More than just aesthetics, the sleek lines significantly improve the aerodynamics of the RX, and optimise fuel efficiency. Overseas model shown.
The RX seats, based on an ergonomic design, put equal emphasis on comfort and accessibility.
A Lexus-first allows you to open and close your rear hatch by simply holding your hand near the emblem. Available on Limited models.
SMART KEY ACCESS AND ILLUMINATION
With the smart key on you, the car senses your arrival and conveniently unlocks the doors. The door handles even feature a illuminaiton line allowing passengers to locate the door handle easily.
CRAFTED SHIFT KNOB
A beautifully ornamented leather shift knob, designed to fit snugly into the hand, is just another example of Lexus’s dedication to detail.
LED CORNERING LIGHTS
Wide-angle cornering lamps provide additional illumination when you take corners, ensuring excellent pedestrian visibility.
UNDER THE HOOD
Under the bonnet, the Lexus RX 450h is powered by a 3.5L Atkinson cycle V6 engine amplified by the Lexus Hybrid Drive system for a total system output of 230kW
DRIVE MODE SELECT
Drive Mode Select provides integrated control of multiple systems to let you tune performance to suit your driving style. Switch between three drive modes (NORMAL, ECO and SPORT) to enjoy pure driving pleasure.
The RX’s high-rigidity body means no matter how aggressively you drive it, your ride is going to be smooth.
Compact and highly-rigid MacPherson struts and lower arms, used for the front suspension, ensure excellent vehicle stability and steering response.
EXCLUSIVE TO RX 450h
LEXUS HYBRID DRIVE
By combining an electric motor and a finely-tuned petrol engine, the RX 450h delivers extra power and instant torque. Fuel consumption is greatly reduced to 5.7 L/100km, and all this without compromising performance.
HYBRID SYSTEM INDICATOR
The meter displays real-time information about the hybrid system’s output and regeneration, encouraging you to adopt an eco-friendly drive.
EV DRIVE MODE
The EV drive mode allows you to enjoy electric motor-only driving at low speeds. This is useful for quietly driving around residential areas at night and in the early morning as well as emissions-free driving in areas such as parking garages.
Every drop goes a longer way with the D-4S engine, which delivers high performance, excellent fuel economy and low emissions.
FROM TACH TO ECO METER
In the mood for a sportier drive? The Hybrid System Indicator changes to a tachometer when you select SPORT mode.
A high strength, collision-absorbing body structure protects you and your loved ones from impacts on the front, rear, sides and roof.
RX 450h also features the Lexus Safety System +. This technology includes Pre-Crash Safety System (Pre-Crash Brake Assist, Pre-Crash Brake), Dynamic Radar Cruise Control (All Speed), Lane Departure Alert (LDA) with Vehicle Sway Warning and a Adaptive High Beam System (AHS).
LANE DEPARTURE ALERT
Lane Keeping Assist uses specialised cameras to monitor the lane markings on the highway, notifying the driver if the vehicle begins to drift. LKA gently applies steering inputs through the Electric Power Steering (EPS) when the vehicle shows signs of departing from the centre of the current lane, assisting and prompting the driver to take action. The system is simply over-ridden should an actual lane change be required using normal steering force.
The parking assist monitor accurately guides your parking attempts by superimposing projected parking lines on the back camera’s video feed.
TYRE PRESSURE ALERT
When low tire pressure is detected, the multi-information display alerts you of the affected tire with an in-meter warning lamp.
BLIND SPOT MONITOR
Know when vehicles are approaching in your blind spot, even at higher speeds with the Blind Spot Monitor fitted with a radar that detects up to 60 meters. Overseas model shown.
10 SRS AIRBAGS
Collision impact is greatly reduced with 10 sensor-controlled airbags lining the cabin, providing enhanced protection for all occupants.
Engine Type Atkinson Cycle 3.5 Litre V6 Petrol Engine Quad-Cam with Variable Valve Timing-intelligent (VVT-iW) for intake and VVT-i for Exhaust Valve Mechanism Capacity 3,456 cc Bore x Stroke 94.0 x 83.0 mm Compression Ratio 13.0 Fuel System Electronic Fuel Injection (EFI) Fuel Consumption (Urban/Extra-Urban/Combined) 5.7/5.6/5.7 L/100km
These figures are produced under controlled conditions for comparative purposes only*
CO₂ Emissions (Combined) 131 g/km
Max. Speed 200 km/h Acceleration 7.7 sec (0 - 100 km/h) Max Power 193 kW / 6,000 rpm
Transmission Type Electronically controlled Continuously Variable Transmission (ECVT) Drive Type All Wheel Drive Brakes Front Ventilated Disc Rear Ventilated Disc Suspension Front MacPherson strut and Stabilliser Bar
Rear Double Wishbone and Stabiliser Bar Steering System Electronic Power Steering (EPS)
Overall Length 4,890 mm Width 1,895 mm Height 1,685 mm Wheelbase 2,790 mm Track Front 1,640 mm Rear 1,630 mm Min. Turning Circle (Tyre) 11.6m Weight Kerb Weight 2105 kg - 2210 kg Gross Vehicle Weight 2715 kg Luggage Capacity Fuel Tank Capacity 65 l
WHEELS AND TYRES
235 / 55 R20 Tyres
20", 10-spoke, Alloy Wheels
Wheel Colour Two tone Medium Grey Metallic
Wheel Finish Machined surface Spare Wheel Type Temporary
Motor Generator Motor Type Permanent Magnet Motor System Performance Total System Output 230 kW Front Motor Motor Type Permanent Magnet Motor
The models selected have the same features.
Instrument Panel 3D Film (Glossy)
Steering Wheel 3 Spoke Leather Steering Wheel with Audio, Multi-Information Display, Telephone, Voice Recognition, Dynamic Radar Cruise Control, Lane Departure Alert Controls
Accessory 12V Power Outlet (x4) 12V DC accessory socket on instrument panel beside front console box, in centre console box, on rear of console box and in the luggage area Inside Rear View Mirror Automatic Day/Night Interior Rear View Mirror Power Back Door Automatic Stop Position Memory Function
Pinch Prevention sensor
Bluetooth Hands-free Phone Capability Hands-free Telephone
Centre Console Box Console Box With Synthetic Leather Arm Rest
Removable Mini Box
Air Conditioning Dual Zone
LCD Temperature display each side of air-conditioning buttons
Clean Air Filter with Pollen Removal
Warnings Door Ajar Warning (Side doors and boot)
Driver and Passenger Seat Belt Warning
Rear Passenger Seatbelt Warning
Door Scuff Plate Stainless Steel front and rear. Front with "LEXUS" Plate
Combination Meter Driving Mode Ambient Illumination (Displayed on TFT MID) ECO mode
Sun Visors Driver's Side and Front Passenger Side
Mirror (sliding cover)
Cup Holders Front x 2 - 3 point support, 1 with vertical sliding height adjustment
Rear x 2 (In arm rest)
Assist Grips Front x 2 (Rotary Type)
Rear x 2 (Rotary Type with coat hook)
Gear Lever Smooth Leather Gear Lever - Silver painted Ornamentation
Shift Lever Boot
Seating Material Main Seat Material: Smooth Leather with perforations (Quilted Finish)
Driver's Seat (Seat Type) Standard
Power Adjustments 8 way
8-way Power Front Passenger Seat with Height, Slide, Recline and Cushion Tilt Adjustments, Lumbar Support (2 way), Memory Function (for Driver seat only)
Rear Seats Three Person Rear Seat
Manual Seat Slide - 120mm
60/40 Split Second Row Seats with Manual Recline and Folding Functions
Manual Height Adjustment
Combination Meter and Displays
Two Large Ring Style Meters
Speedometer (Analogue, 260km/h)
Tachometer (Analogue, 7,000 rpm)
Multi Information Display with 4.2 inch LCD colour screen that includes: Drive Mode Indicator, Shift Position Indicator, Outside Temperature, Driving Information, Energy Monitor
Hybrid System Indicator (Charge/ECO/Power)
Audio / Entertainment / Display
Audio Head Unit AM/FM Radio
Single Disc Player
CD / DVD Playback
CD-R/ CD-RW / CD MP3 / CD WMA
Satellite Navigation (SD Card for Map Updates)
USB Port x 2
Audio Input Jack - 3.5mm
Audio Speakers / Amplifier Pioneer Audio
Speakers x 12
EMV Display - Hoodless Design 12.3" EMV (Electro Multi Vision) Display
Alarm - Siren, Horn and Hazard lamps
Interior Ultrasonic Break-in Sensor
Glass Break Sensor
Airbags 10-airbag System
Front Passenger Side
Drivers Knee Airbag
Passenger Cushion Airbag
Rear Seat Side Airbags
Curtain Shield Airbags (both Sides)
Active Safety Anti-Lock Braking System (ABS)
Electronic Brake-force Distribution (EBD)
Brake Assist (BA)
Emergency Stop Signal (ESS)
Hill Start Assist Control (HAC)
Vehicle Stability Control (VSC)
Traction Control (TRC)
Electronically Controlled Brake System (ECB)
Vehicle Dynamics Integrated Management (VDIM)
Lexus Safety System + Pre-Crash Safety System
Pre-Crash Brake Assist
Pre Brake Warning
PCS on/off switch (In Multi Information Display)
Dynamic Radar Cruise Control System
All Speed Dynamic Radar Cruise Control (DRCC)
Lane Keeping Assist System
Lane Departure Alert (LDA) with Steering assist
Lane-keeping Assist (LKA)
Vehicle Sway Warning System
Lane Change Assist System Blind Spot Monitor (BSM)
Rear Cross Traffic Alert (RCTA)
Child Restraint System ISO-Fix x2 - Outer Rear Seats
Tether Anchor x3 - Rear Seats
Seatbelts Front Seat Belts
3-Point Seat Belts x 2
Emergency Locking Retractor (ELR)
Force Limiters (FL)
Manually Adjustable Seat Belt Anchors
Rear Seat Belts
3-Point Seat Belts x 3
Emergency Locking Retractor (ELR)
Outside Seats - Pre-Tensioners (PT)
Outside Seats - Force Limiters (FL)
Parking Assist Monitor Moving Guidance Lines
Perpendicular Parking Mode
Parallel Parking Mode
Parking Assist Sensors 4 x Front (2 x Corner, 2 x Centre)
4 x Rear (2 x Corner, 2 x Centre)
The models selected have the same features.
* Your actual fuel consumption will vary from that shown, depending on factors such as vehicle condition and any vehicle modifications, driving style, traffic conditions, distance travelled and fuel price variations, Visit http://www.nzta.govt.nz/vehicles/vehicle-types/vehicle-classes-and-standards/environmental-standards/ for more information.
